AND (A&D) AD-3255 Ultrasonic Thickness Meter

Manufaturer:	AND Company Limited
Model:	AD-3255

Product code

1-75-53705

Price 1,229.76 USD

Add to cart Buy now

*This is standard price, please click "Request a quote" to see the actual price.

*You can't find the product you need, please send us the picture/specifications/model/product code and quantity you need to email: info@qtetech.com.vn. We will find it for you.

Description

standard probe
Measurement method: Ultrasonic pulse reflection method
Frequency of measurement: Single point mode/7 times/sec, scan mode/16 times/sec
External dimensions : ( W ) 73 x ( D ) 32 x ( H ) 143mm
Measurement range (pulse eco-mode):
*7MHz probe, for AD -3255 - 02 (standard attached probe): 0.8 to 200.0mm
*5MHz probe, for AD -3255 - 03 (optional probe): 1.0 to 300.0mm
5MHz probe, for AD -3255 - 04 (optional probe): 2.0 to 300.0mm
Accuracy of measurement:. + -. 0.1mm ±0.5% (Measuring range: 0.8 to 50.0mm),. + -. 0.1mm ±1.5% (Measuring range: 50.1 to 300.0mm)
*The performance and accuracy of the measurement depend on the state of the workpiece surface.
Accuracy guarantee temperature range: 5 to 40 ℃
Variable speed range: 1000 to 9999 m/s
Display range: 0.65 to 600.0mm
Display Resolution: 0.01 mm/0.1mm selected (However, 200.1mm and above are displayed as resolution/0.1 mm.)
Power supply : AA size battery x 2 pieces (Sold separately)
Size: 73 x 32 x 143mm
Weight : about 160g (excluding battery)
Accessories: 7MHz probe (AD -3255 -02), 4mm equivalent specimen (AD -3255 -01), carrying case strap, empty bottle for contact medium
