Yokogawa Electric TY520 Digital Multimeter (measure temperature, capacitance, voltage, current and resistant value)

Yokogawa Electric TY520 Digital Multimeter (measure temperature, capacitance, voltage, current and resistant value)

Manufaturer: Yokogawa Electric
Model: TY520
Product code
1-80-58588
Price 330.56 USD
Add to cart Buy now

✔ Note: Displayed prices are standard prices.

⚡ Please click Request a quote to unlock Competitive pricing and delivery dates within 24 hours.

✅ Guaranteed 100% Genuine (CO/CQ) – Free quote.

✈️ We deliver to your doorstep under DAP terms. Customs clearance is for your account.

✉️ Can't find the product you need? Please send the picture/specifications/model/product code to [email protected]. We will find it for you.

⭐ Review us here: Review Now ★ Trustpilot

Description

  • It is a multi-meter that can measure temperature, capacitance, voltage, current and resistant value.
  • It has easy-to-read bar graph display(31 steps).
  • TY530:Memory Function Provided.
  • DC voltage, AC voltage: 600mV, 6V, 60V, 600V, 1000V
  • DC current, AC current: 600μA, 6000μA, 60mA, 600mA, 6A, 10A
  • Resistance: 600Ω, 6kΩ, 60kΩ, 600kΩ, 6MΩ, 60MΩ
  • Frequency: 10.00 - 99.99Hz, 90.0 - 999.9Hz, 0.900 - 9.999Hz, 9.00 - 99.99kHz
  • Capacitance: 10nF, 100nF, 1μF, 10μF, 100μF, 1000μF
  • Temperature: -50 - 600℃
  • Function: Data hold, deviation/% calculation, auto power off, backlight
  • Withstand voltage: 6.88kV for 5 seconds
  • Power supply: AA battery x 4 (included for test)
  • Weight: Approximately 570g (including cell)
  • Safety standards EN61010-1, CATIII1000V, CATIV 600V
  • EMC standards: EN61326-1, EN55011 Class B
  • Accessories: Test lead x 1 set, fuse (440mA/1000V and 10A/1000V)
  • Size: 90 x 49 x 192mm
  • Weight: Approx 570g
  • Model number: TY520
