SMC TU0604BU-100 Polyurethane tube (6mm x 100m, blue)
| Manufaturer: | SMC Corporation |
| Model: | TU0604BU-100 |
*The above price is Standard Price, Kindly click on Request a quote to unlock the Best Price and Delivery Date. Our expert consulting team is always ready to assist you.
*Order Process: 1. Request a quote ⇒ 2. Quote via Email ⇒ 3. Proforma Invoice ⇒ 4. Payment ⇒ 5. Delivery and Invoice.
*We deliver to your doorstep under DAP terms. Customs clearance is for your account.
*You can't find the product you need, please send us the picture/specifications/model/product code and quantity you need to email: [email protected]. We will find it for you.
*Review us here: Review Now
Description
- The bending radius is very small, making it easy to handle.
- Can be used for general industrial water.
- It has excellent flexibility.
- General pneumatic piping
- For piping that requires flexibility
- Color: Blue (semi-transparent)
- Outer diameter (mm): 6
- Inner diameter (mm): 4
- Minimum bending radius (mm): 15
- Fluids used: air, water
- Total length (m): 100
- Fluid temperature (℃): Air -20 to 60℃, Water 0 to 40℃ (no freezing)
- Operating pressure: 0.8MPa or less (at 20℃)
- Material/Finish: Polyurethane
- Note: Operating pressure will vary depending on tube diameter and operating temperature.
- Country of Origin: Japan
- Code number: 394-5570
-
Frequently Asked Questions (FAQs):
Q1: Can this tubing handle vacuum service?
Yes. While primarily rated for positive pressure, its wall thickness withstands moderate vacuum levels without collapsing in standard pneumatic applications.
Q2: Are there color-coding options for zone identification?
SMC’s TU series offers 8+ colors. Blue simplifies water-return lines; other colors can delineate different air zones for maintenance clarity.
Q3: How does polyurethane compare to nylon tubing?
Polyurethane offers superior elasticity and abrasion resistance, whereas nylon provides higher burst pressure but is more rigid and prone to scuffing.
Q4: Is this tubing FDA-compliant for food-grade air?
The TU series is RoHS-compliant but not specifically FDA-approved. Consult QTE Technologies (qtetech.com/en) for food-grade polyurethane or fluoropolymer alternatives.
Q5: Can I use this tubing with hydraulic fluids?
No. It’s formulated for air and water. Hydraulic oils can swell or degrade the polyurethane.
Q6: What fittings are recommended?
Use SMC push-in fittings (e.g., KQ2, KQG series) sized for 6 x 4mm tubing to ensure leak-free, tool-free connections.
