Schneider Electric LRD06 Overload Relay (NO/NC, 1 - 1.6A, 1.6A)

Manufaturer:	Schneider Electric
Model:	LRD06

Product code

111-61967

Price 83.13 USD

Add to cart Buy now

*The above price is Standard Price, Kindly click on Request a quote to unlock the Best Price and Delivery Date. Our expert consulting team is always ready to assist you.

*Order Process: 1. Request a quote ⇒ 2. Quote via Email ⇒ 3. Proforma Invoice ⇒ 4. Payment ⇒ 5. Delivery and Invoice.

*You can't find the product you need, please send us the picture/specifications/model/product code and quantity you need to email: [email protected]. We will find it for you.

*Review us here: Review Now

Description

overload relay
Either AC or DC can be used to power the relay.
1 x NO and 1 x NC contact.
Trip fault indication.
Manual or automatic reset button.
For more information, see Contactors/Accessories for Telemecanique TeSys D Products.
Trip class 10 A
Quantity: 1 piece
Motor rated current: 1→ 1.6 A
Contact current rating: 1.6 A
Polar setting: 3P
Range: TeSys
Contact rated voltage: 690V ac
Installation style: direct contactor
Series: LRD0
Normal state configuration: NO/NC
Number of auxiliary contacts: 2
Reset method: automatic, manual
Width: 45mm
Operating temperature range: -20→ +60°C
RoHS compliance status: Not applicable
Code number: 394-9419
