RS Pro 291-9647 SPNO Reed Relay (0.5 A, 24Vdc)

Manufaturer:	RS PRO
Model:	291-9647

Product code

111-68466

Price 35.89 USD

Add to cart Buy now

*The above price is Standard Price, Kindly click on Request a quote to unlock the Best Price and Delivery Date - Check Availability. Our expert consulting team is always ready to assist you.

*Order Process: 1. Request a quote ⇒ 2. Quote via Email ⇒ 3. Proforma Invoice ⇒ 4. Payment ⇒ 5. Delivery and Invoice.

*We deliver to your doorstep under DAP terms. Customs clearance is for your account.

*You can't find the product you need, please send us the picture/specifications/model/product code and quantity you need to email: [email protected]. We will find it for you.

*Review us here: Review Now

Description

SPNO DIL relay
Ideal for mains triac trigger devices
Normally open contact, capable of switching 240V AC mains Industry standard pin configuration Coil suppression diode between pins 2 and 6 Operating temperature: -20 to +70°C
Quantity: 1 piece
Contact configuration: SPNO
Coil voltage: 24V dc
Mounting Type: PCB Mount
Maximum switching current AC: 0.5 A
Maximum switching current DC: 0.5 A
Maximum switching voltage AC: 300V
Maximum switching voltage DC: 300V dc
Coil power: 290mW
Coil resistance: 2.15kΩ
Length: 19.3mm
Height: 7.5mm
Depth: 7mm
Dimensions: 19.3 x 7 x 7.5 mm
Withstand voltage between coil and contacts: 2.5kV dc
Operating temperature Min: -20°C
RoHS Compliance Status: Compliant
Code number: 291-9647
