SANWA ELECTRIC INSTRUMENT LP1 Laser Power Meter (40.00μW, 400.0μW, 4.000m, 40.00mW)

SANWA ELECTRIC INSTRUMENT LP1 Laser Power Meter (40.00μW, 400.0μW, 4.000m, 40.00mW)

Manufaturer: SANWA ELECTRIC INSTRUMENT
Model: LP1
Product code
1-75-53723
Price 194.79 USD
Product discontinued
Add to cart Buy now

✔ Note: Displayed prices are standard prices.

⚡ Please click Request a quote to unlock Competitive pricing and delivery dates within 24 hours.

✅ Guaranteed 100% Genuine (CO/CQ) – Free quote.

✈️ We deliver to your doorstep under DAP terms. Customs clearance is for your account.

✉️ Can't find the product you need? Please send the picture/specifications/model/product code to [email protected]. We will find it for you.

⭐ Review us here: Review Now ★ Trustpilot

Description

  • Photo acceptance unit: Si photodiode (φ9mm)
  • Measurement wavelength range 400 - 1100nm
  • Direct reading calibration wavelength: 633nm (He-Ne laser) standard type
  • (As for other wavelength, representative compensating rate is used for conversion)
  • Display: Numerical value part/3999 counts, Bar-graph part/42 segments
  • Sample rate: Numerical value part/Approximately 2 times per second, Bar-graph part /Approximately 20 times per second
  • Measurement range: 40.00μW, 400.0μW, 4.000m, 40.00mW
  • Accuracy: ±5% (1mW: 4mW ranges, At 633nm) 23℃±2℃
  • Power supply: LR-44 battery x 2 pieces (optional)
  • Power consumption: Approximately 6mW
  • Used temperature and humidity range: Temperature/0℃ - 40℃, Humidity/80%RH or less, no condensation
  • Storage temperature and humidity range: Temperature/-10℃ - 50℃, Humidity/80%RH or less, no condensation
  • Size: Body/W76 x D18 x H117mm, Sensor probe/W16 x D10 x H84mm
  • Weight: Approx 120g
  • Cord length: 500mm
