2/ What type of illumination does it employ?

It uses a white LED light source transmitted from the base, offering stable, uniform illumination with low heat generation and long lifespan.

3/ How do I focus and move the stage?

Focusing is achieved via a uniaxial coarse-and-fine adjustment knob. The mechanical stage measures 124 × 110 mm and includes sample holders for precise X-Y movement.

4/ When should I clean and maintain the microscope?

After every oil-immersion session, wipe off immersion oil immediately with lens-grade filter paper. Perform a full optical and mechanical check every 3–6 months, including lens cleaning and lubrication of moving parts.

7/ What are the power requirements?

It operates on 85–265 V at 50/60 Hz, uses a 250 V/0.5 A fuse, and comes with a ~1.65 m power cord and a standard 3-pin plug.

8/ What should I do if the LED flickers or fails to light?

First check that the power switch and cord are secure and undamaged. Verify the fuse isn’t blown. If the problem persists, contact an authorized service center for LED module inspection or replacement.
