TRUSCO NAKAYAMA MAG-11 Air gun (spraying of chips, powder, fiber waste, smoke, etc) (0.6MPa, 350L/min)

Manufaturer:	TRUSCO NAKAYAMA CORPORATION
Model:	MAG-11

Product code

111-66944

Price 166.62 USD

Add to cart Buy now

*The above price is Standard Price, Kindly click on Request a quote to unlock the Best Price and Delivery Date. Our expert consulting team is always ready to assist you.

*Order Process: 1. Request a quote ⇒ 2. Quote via Email ⇒ 3. Proforma Invoice ⇒ 4. Payment ⇒ 5. Delivery and Invoice.

*You can't find the product you need, please send us the picture/specifications/model/product code and quantity you need to email: [email protected]. We will find it for you.

*Review us here: Review Now

Description

You can suction and spray just by changing the direction of the nozzle.
How to switch between suction and injection: Unscrew the suction pipe, remove the O-ring and nozzle, then switch the nozzle direction.
Cleaning, transporting and spraying of chips, powder, fiber waste, smoke, etc.
Intake outer diameter (mm): 20.0
Exhaust outer diameter (mm): 25
Total length (mm): 142
Air consumption (L/min): 350
Air inlet: 1/4 plug
Maximum operating pressure: 0.6MPa
Material/Finish: Body/Aluminum die-cast, Nozzle/Aluminum alloy
Note: How to switch between suction and injection: Refer to step 4 in the instruction manual, turn and remove the suction pipe, then step 3, remove the nozzle and reverse the direction back and forth.
Country of Origin: Japan
Code number: 227-5759
