SMC PF2D504-11-1 Flow Switch (DC12 - 24V +/- 10%, 0.4 - 4L/min)

Manufaturer:	SMC Corporation
Model:	PF2D504-11-1

Product code

111-55932

Price 806.72 USD

Add to cart Buy now

*The above price is Standard Price, Kindly click on Request a quote to unlock the Best Price and Delivery Date. Our expert consulting team is always ready to assist you.

*Order Process: 1. Request a quote ⇒ 2. Quote via Email ⇒ 3. Proforma Invoice ⇒ 4. Payment ⇒ 5. Delivery and Invoice.

*You can't find the product you need, please send us the picture/specifications/model/product code and quantity you need to email: [email protected]. We will find it for you.

*Review us here: Review Now

Description

Measurement fluid: Pure water and liquid that does not corrode or penetrate fluorine resin, However viscosity is 3mPa・s (3cP) or less
Liquid junction material (sensor): Body, sensor/PFA (fluorine resin), Tube/PFA (fluorine resin)
Tube specification (sensor): 3/8 inch tube
Temperature of used liquid: 0 - 90℃
Output specification (monitor): Maximum load current:/80mA, Internal drop voltage/1V or less, Maximum applied voltage/30V 2 outputs
Power voltage: DC12 - 24V +/- 10%
Rated flow rate range (L/min): 0.4 - 4
Output specification: Output for monitor + analog output (1 - 5V)
Model number: PF2D504-11-1 (sensor)
