SANWA SUPPLY BCR-006 Laser Barcode Reader 1D

Manufaturer:	SANWA SUPPLY
Model:	BCR-006

Product code

111-68234

Price: Contact

Add to cart Buy now

*The above price is Standard Price, Kindly click on Request a quote to unlock the Best Price and Delivery Date. Our expert consulting team is always ready to assist you.

*Order Process: 1. Request a quote ⇒ 2. Quote via Email ⇒ 3. Proforma Invoice ⇒ 4. Payment ⇒ 5. Delivery and Invoice.

*We deliver to your doorstep under DAP terms. Customs clearance is for your account.

*You can't find the product you need, please send us the picture/specifications/model/product code and quantity you need to email: [email protected]. We will find it for you.

*Review us here: Review Now

Description

High-speed reading is possible with a reading performance of 300 scans per second.
Equipped with a laser sensor, it has high visibility and readability, making it suitable for reading densely packed barcodes.
By using the included stand, you can read the card simply by holding it up to the reader (auto-sensing function supported).
You can turn the auto-sensing function on and off by pressing and holding the scan button without using an option code.
It is waterproof and dustproof to IP54 standard.
You can also mute the sound that is emitted when a barcode is scanned, which is convenient when using the scanner in a quiet place.
Interface: USB specification Ver.2.0 compliant (upward compatible with USB Ver.1.1)
Barcode types: JAN, EAN-8, EAN-13, UPC-A, UPC-E, Code 39, Code 93, Code 128, EAN128, NW-7 (Codabar), Industrial 2 of 5, Interleave 2 of 5, Matrix 2 of 5, MSI
PCS value: ≥ 10%
Light source: Visible light semiconductor laser (650nm)
Scan speed: 300 scans/second
Connector type: USB A connector
Resolution: 3mil
Sensor: Laser
Protection structure: IP54
Power supply: 5VDC
Reading depth: 0-330mm
Current consumption: 85mA
Anti-disturbance light: 3000~8000lux
Impact resistance: 1.5m
Skew angle: 65°
Pitch angle: 55°
Environment: Operating temperature/0~50℃, Humidity/5~85%, Storage temperature/-40~70℃, Humidity/5~85%
*No condensation
Readable codes: 1D/JAN, EAN-8, EAN-13, UPC-A, UPC-E, Code 39, Code 93, Code 128, EAN128, NW-7 (Codabar), Industrial 2 of 5, Interleave 2 of 5, Matrix 2 of 5, MSI
*Some barcodes cannot be read depending on their size and number of digits.
Size: W73 x D175 x H102mm
Weight: approx. 246g
Cable length: Approx. 2m
Accessories: Stand, instruction manual
