RS PRO 733-5261 High Pressure Ball Valve Brass

Manufaturer:	RS PRO
Model:	733-5261

Product code

111-67693

Price 38.26 USD

Add to cart Buy now

*The above price is Standard Price, Kindly click on Request a quote to unlock the Best Price and Delivery Date. Our expert consulting team is always ready to assist you.

*Order Process: 1. Request a quote ⇒ 2. Quote via Email ⇒ 3. Proforma Invoice ⇒ 4. Payment ⇒ 5. Delivery and Invoice.

*You can't find the product you need, please send us the picture/specifications/model/product code and quantity you need to email: [email protected]. We will find it for you.

*Review us here: Review Now

Description

Freezing of liquids within the installation can cause severe damage to the valve.
DVGW (Germany) SVGW (Switzerland) BSI (UK) Factory Mutual (USA) The Australian Gas Association (Australia) GOST-R (Russia) Expert Conclusion (Russia) EAC Conforming (Russia) Suruhanjaya Tenaga (Malaysia) UkrSepro (Ukraine) RoHS Compliant
Apply approvals to specific configurations only
S.84 EN331 Brass Ball Valve 1/4 Turn Male/Female
Legionella is a bacterium that lives and grows in natural and artificial water environments at temperatures between 5.7°C and 55°C, and can live in both acidic and alkaline environments. The new S.84 is certified for gas use and is now certified for drinking water use. The specific ball design prevents water stagnation and the spread of bacteria within the mechanism.
Applications: Gas, Oil, Water, Drinking Water Operating Temperature: -40 °C (-40 °F) / +170 °C (+350 °F) Operating Pressure: PN40 (600 PSI) up to 2 inches, PN30 (450 PSI) for 2.5 → 4 inches, non-shock cold operating pressure Rated for hazardous liquids at temperatures -20 → +60 °C and pressure ratings of 5 bar Thread: EN10226-1, ISO228, parallel thread Ports: Full Connection Options: FxF, MxF, BSPP, BSPT Stem Configuration: Blow-out proof nickel plated brass stem, 2 FPM O-rings fitted on stem for maximum safety Ball Valve Seat: Genuine PTFE self-lubricating, flexible lip design Body: Full ports according to DIN3357 for maximum flow 100% Made in Italy Long life chrome plated brass ball with holes for cleaning fluids Silicone-free lubricant on all seals Stroke stop on body eliminates pressure on stem 24-hour 100% seal test guarantee Dual seal system simplifies installation by allowing valve to be operated in both directions No metal-to-metal moving parts Maintenance-free Handle with clear ball position Quality: Hot-forged, sand-blasted nickel-plated brass body, cap with Loctite or equivalent thread sealant seal, best brass to EN12165 and EN12164 (formerly DIN17660 and UNI5705-65) standards
Quantity: 1 piece
Threaded connection: 1/2 in BSPP
Attachment Type: Screw
Body material: Brass
Thread size: 1/2 inch
Safe to use: Gas
Connection size in inches: 1/2 inch
Handle color: Yellow
Maximum working pressure psi: 3625psi
Handle material: PVC coated steel
Handle Type: Lever
RoHS Compliance Status: Compliant
Code number: 733-5261
