RS Pro 671-9019 Toroidal transformer (2 Output, 160VA, 2 x 12VAC)

RS Pro 671-9019 Toroidal transformer (2 Output, 160VA, 2 x 12VAC)

Manufaturer: RS PRO
Model: 671-9019
Product code
111-67313
Price 181.94 USD
Add to cart Buy now

✔ Note: Displayed prices are standard prices.

⚡ Please click Request a quote to unlock Competitive pricing and delivery dates within 24 hours.

✅ Guaranteed 100% Genuine (CO/CQ) – Free quote.

✈️ We deliver to your doorstep under DAP terms. Customs clearance is for your account.

✉️ Can't find the product you need? Please send the picture/specifications/model/product code to [email protected]. We will find it for you.

⭐ Review us here: Review Now ★ Trustpilot

Description

  • Ensure that both ends of the fixing bolt do not contact the metal chassis or frame at the same time as this could result in a dangerous short circuit of the windings.
  • UL506, EN61558
  • Mounting hardware not included (sold separately)
  • Toroidal open winding type, primary 230 V
  • High quality open type toroidal transformer, one 230 Vac 50/60 Hz primary winding.
  • The two secondary windings can be connected in series or parallel, or used independently.
  • Smaller and lighter than conventional laminated thin plate types Ultra-low level of radiated electromagnetic waves Very low induced noise (hum) Very low iron loss Double insulated primary leads
  •
  • Quantity: 1 piece
  • Primary voltage rating: 230V ac
  • Secondary voltage rating: 2 x 12V ac
  • Rated power: 160VA
  • Number of outputs: 2
  • Secondary current: 6.667A
  • Height: 46mm
  • Weight: 1.7kg
  • Diameter: 109mm
  • Dimensions: 109 (Dia.) x 46mm
  • Minimum operating frequency: 50Hz
  • Maximum operating frequency: 60Hz
  • Termination Type: Copper Conductor
  • RoHS Compliance Status: Compliant
  • Code number: 671-9019
