ORION ELECTRIC RAX22J Standard Refrigerated Air Dryer (RAX Small Series) (3.90/ 4.50m3/min, 0.2 - 0.98 MPa)

ORION ELECTRIC RAX22J Standard Refrigerated Air Dryer (RAX Small Series) (3.90/ 4.50m3/min, 0.2 - 0.98 MPa)

Manufaturer: ORION ELECTRIC
Model: RAX22J
Product code
111-61334
Price 4,062.46 USD
Add to cart Buy now

✔ Note: Displayed prices are standard prices.

⚡ Please click Request a quote to unlock Competitive pricing and delivery dates within 24 hours.

✅ Guaranteed 100% Genuine (CO/CQ) – Free quote.

✈️ We deliver to your doorstep under DAP terms. Customs clearance is for your account.

✉️ Can't find the product you need? Please send the picture/specifications/model/product code to [email protected]. We will find it for you.

⭐ Review us here: Review Now ★ Trustpilot

Description

  • This is a high temperature environment compatible type that can be operated even at an ambient temperature of 45℃.
  • Adopts a stainless steel shell heat exchanger.
  • Equipped with a suction filter as standard.
  • Single phase 200 and 220V are also available. (separate part number)
  • For dehumidifying compressed air sent from a compressor
  •
  • Processing air flow rate 50/60Hz (m3/min): 3.90/4.50
  • Power supply (V): Three-phase 200
  • Power consumption (kW) (50/60Hz): 0.65/0.79
  • Connection size: R1
  • Width (mm): 240
  • Depth (mm): 870
  • Height (mm): 580
  • Refrigerant: R-410A
  • Current (50/60Hz): 3.0/2.8A
  • air cooled
  • Fluid used: Compressed air
  • Inlet air temperature: 5-50℃
  • Working pressure range: 0.2~0.98MPa
  • Outlet air dew point: 10℃ (under pressure)
  • Ambient temperature range: 2 to 45°C (at power supply pressure ±5%), 2 to 40°C (at power supply pressure ±10%)
  • Material/Finish: Steel plate
  • Note: This item will be delivered directly on the vehicle.
  • Country of Origin: Japan
  • Code number: 836-1319
