Optek OPB720B-06Z Optical Sensor (reflective type, 152mm, 3-Pin, 1 bag (25pcs))

Manufaturer:	Optek
Model:	OPB720B-06Z

Product code

111-67866

Price 1,236.18 USD

Add to cart Buy now

*The above price is Standard Price, Kindly click on Request a quote to unlock the Best Price and Delivery Date. Our expert consulting team is always ready to assist you.

*Order Process: 1. Request a quote ⇒ 2. Quote via Email ⇒ 3. Proforma Invoice ⇒ 4. Payment ⇒ 5. Delivery and Invoice.

*You can't find the product you need, please send us the picture/specifications/model/product code and quantity you need to email: [email protected]. We will find it for you.

*Review us here: Review Now

Description

OPB720A/OPB720B Long Range Reflective Switches
The OPB720 series features a logic output that switches from high with a reflective target to low with no reflective target. Additional hysteresis allows the sensor to minimize switching oscillations in the output. The achievable sensor distance is highly dependent on the type of material used for the target.
Recognizes 2 mm objects Can be used in reflective or blocking modes Ambient light rejection; 100k Lux TTL/CMOS compatible Cable length: 990 mm Size: 27.94 x 8.38 x 17.15mm
Applications: package recognition on conveyor belts, human movement recognition, near-focus security systems, detergent mixing stations, product mixing services, etc.
Quantity: 1 bag (25 pieces)
Peak sensor distance: 152mm
Output device: Open collector
Number of channels: 1
Number of pins: 3
Dimensions: 17.15 x 8.38 x 27.94mm
Height: 27.94mm
Length: 17.15mm
Operating temperature Max: +70°C
Operating temperature Min: 0°C
Width: 8.38mm
Operating temperature range: 0 to +70°C
RoHS Compliance Status: Compliant
Code number: 170-0732
