NIDEC DRIVE TECHNOLOGY FGJN-50 Force gauge No output 500N

NIDEC DRIVE TECHNOLOGY FGJN-50 Force gauge No output 500N

Manufaturer: NIDEC DRIVE TECHNOLOGY
Model: FGJN-50
Product code
111-63764
Price 833.68 USD
Add to cart Buy now

*This is standard price, please click "Request a quote" to see the actual price.

*You can't find the product you need, please send us the picture/specifications/model/product code and quantity you need to email: info@qtetech.com.vn. We will find it for you.

Description

  • Force gauge compatible with simple tests in series from 20.00N (2kg) to 500.0N (50kg)
  • Improved measurement accuracy and measures peak values ​​at a high speed of 1000 times/second.
  • Normal measurement can be selected up to 20 times/second.
  • The display cycle is 1 times/second, 2 times/second, 3 times/second, 5 times/second, 10 times/second, 20 times/second.
  • Adopts a reverse type that allows the displayed numerical value and display unit to be displayed upside down with one touch.
  • Switching between units of N and kg(g) is possible with one touch.
  • Peak value measurement possible
  •
  • Rated capacity (RC): ±500.0N (±50.00kg)
  • Displayable range: ±500.0N ±50.00kg
  • Display resolution: 0.1N/0.01kg
  • Unit: N, kg (can be displayed upside down)
  • Measurement method: 1. Normal measurement 2. Plus peak measurement 3. Minus peak measurement
  • Display cycle: 1 time/second, 2 times/second, 3 times/second, 5 times/second, 10 times/second, 20 times/second
  • Measurement time: 1000 times/second
  • Accuracy: ±0.3% of rated capacity and ±1/2digit (at 23℃)
  • Temperature effect: Cancelled by tracking processing, span ±0.03%/LOAD/℃
  • Display device: 4-digit liquid crystal display, character height 12mm, pull load is - (can be displayed upside down) various displays 1"LO BAT" (low battery voltage) 2"BAT" (charging) 3"OVR" (over load) 4 "PEAK" (peak hold mode)
  • Overload capacity: 200%/RC
  • Tracking function: Yes (ON/OFF switchable)
  • power supply
  • Rechargeable (built-in nickel metal hydride battery) and AC adapter (DC9V 200mA), measurement possible while charging
  • Usable time: Approximately 8 hours after fully charged
  • Charging time: Up to 12 hours (automatically ends when fully charged)
  • Auto power off function: 10 minutes (can be used continuously when using AC adapter) or OFF
  • Temperature range: 0~40℃
  • Size: width 75 x thickness 38 x length 147mm
  • Weight: Approx. 450g (including battery)
  • Accessories: Measurement adapter (M6), hanger, AC adapter, carrying case
