KYORITSU KC-80 Air Machine Vice KC type 300mm

KYORITSU KC-80 Air Machine Vice KC type 300mm

Manufaturer: KYORITSU
Model: KC-80
Product code
111-66046
Price 1,979.19 USD
Add to cart Buy now

✔ Note: Displayed prices are standard prices.

⚡ Please click Request a quote to unlock Competitive pricing and delivery dates within 24 hours.

✅ Guaranteed 100% Genuine (CO/CQ) – Free quote.

✈️ We deliver to your doorstep under DAP terms. Customs clearance is for your account.

✉️ Can't find the product you need? Please send the picture/specifications/model/product code to [email protected]. We will find it for you.

⭐ Review us here: Review Now ★ Trustpilot

Description

  • The air valve is not attached to the main unit, so the valve can be attached anywhere for remote control.
  • The air stroke is 25mm, but by adjusting the adjustment bolt the mouth can be opened up to a maximum of 50mm.
  • Air machine vice for processing small items.
  •
  • Total length (mm): 300
  • Overall width (mm): 120
  • Overall height (mm): 80
  • Mouth width (mm): 80
  • Mouth opening (mm): 50
  • Mouth depth (mm): 32
  • Tightening force (kN): 2.2 (0.5MPa)
  • Hose attachment port: PT1/8×8
  • Material/Finish: Body/FC250, Base/S45C (raw)
  • Country of Origin: Japan
  • Code number: 751-2830
