KITAGAWA ASP-1200 Air Sampling Pump (10～1200mL/min)

Manufaturer:	KITAGAWA, KOMYO RIKAGAKU KOGYO K. K.
Model:	ASP-1200

Product code

111-59452

Price 1,221.23 USD

Add to cart Buy now

*This is standard price, please click "Request a quote" to see the actual price.

*You can't find the product you need, please send us the picture/specifications/model/product code and quantity you need to email: info@qtetech.com.vn. We will find it for you.

Description

Collection tube/detection tube for continuous suction
Ability to aspirate a wide range from collection tubes to detection tubes
Strong suction power: Easy suction of DNPH cartridges at 1 L/min. Can also suction activated carbon/silica gel/TENAX collection tubes.
10 measurement conditions can be registered
Protects the main body from dust and water droplets equivalent to IP43.
A wide flow rate setting range (10 to 1200 mL/min) is possible
You can check the flow rate, suction volume, etc. on the screen.
Power supply is dry cell or AC power (USB terminal adapter included) *Commercially available Mobal battery can be used
Small size, high performance
Flow rate setting range: 10 to 1200 mL/min (constant flow function)
Flow accuracy
10 to 100 mL/min: ±5 mL/min
100 to 1200 mL/min: ±5% of indicated value
Accumulated flow indication range: 0.0 to 9999.9L (converted at 20°C or 25°C)
Accumulated time indication range: 00:00 to 999:59 (hour: minute)
Modes: timer mode, constant volume mode, extended menu, calibration mode
Built-in flow meter: mass flow sensor
Pump: Diaphragm type
Timer function: standby time, end time setting
Flow rate calibration function: Flow rate calibration is possible in calibration mode
Operating temperature and humidity range: 0 to 40°C, 90% RH or less (no condensation)
Power supply: 4 AA batteries (alkaline batteries, nickel-metal hydride rechargeable batteries or lithium batteries), AC adapter (AC100V-240V, 50/60Hz, main unit side connector USB Micro-B terminal)
Operating time: When using alkaline batteries (no load: 1200 mL/min): 12 hours or more continuously *Varies depending on usage conditions such as temperature.
Dimensions: W145 x H99 x D54mm (excluding protrusions)
Mass: Approx. 500g (including batteries)
Accessories: AC adapter, 4 AA alkaline batteries, 3 replacement filters, 1 connecting tube
Optional items: Dedicated case, impinger holder, impinger hook, 10 replacement filters
