CONTEC AD16-16(LPCI)L Non-isolated high-precision analog input board

CONTEC AD16-16(LPCI)L Non-isolated high-precision analog input board

Manufaturer: CONTEC
Model: AD16-16(LPCI)L
Product code
111-66352
Price 807.51 USD
Add to cart Buy now

✔ Note: Displayed prices are standard prices.

⚡ Please click Request a quote to unlock Competitive pricing and delivery dates within 24 hours.

✅ Guaranteed 100% Genuine (CO/CQ) – Free quote.

✈️ We deliver to your doorstep under DAP terms. Customs clearance is for your account.

✉️ Can't find the product you need? Please send the picture/specifications/model/product code to [email protected]. We will find it for you.

⭐ Review us here: Review Now ★ Trustpilot

Description

  • This is a PCI bus-compliant interface board equipped with high-precision analog input (16bit, 16ch), digital input (4 points), digital output (4 points), and counter (32bit, 1ch).
  • Windows/Linux drivers included.
  • In addition, it is also compatible with programless data collection using the data logger software [C-LOGGER (attached)], and with MATLAB and LabVIEW using the dedicated library plug-in (free download).
  • Enhancement of basic functions
  • Enhanced control functions
  • Equipped with a filter function to facilitate connection of external signals
  • Equipped with buffer memory
  • Software adjustable
  • Supports low profile PCI slots/PCI slots
  •
  • Expansion module (bus specification): PCI
  • Expansion module (size): Low Profile
  • Expansion module (connector used): 1x Miniature ribbon 50-pin
  • Analog input/output (number of input channels): Single-ended 16-ch
  • Analog input/output (input range): ±10V
  • Analog input/output (ADC6-bit
  • Analog input/output (sampling rate): 10μsec/ch (max.)
  • Digital input/output (number of inputs): 4
  • Digital input/output (number of outputs): 4
  • Digital input/output (response speed (input)): 200μsec (max.)
  • Digital input/output (response speed (output)): 200nsec (max.)
  • Digital input/output (operating voltage (input)): 5VDC-TTL
  • Digital input/output (operating voltage (output)): 5VDC-TTL
  • Digital input/output (input circuit): Non-isolated TTL level input (positive logic)
  • Digital input/output (output circuit): Non-isolated TTL level output (positive logic)
  • Counter (number of channels): 1-ch
  • Counter (counting method): 32-bit up
  • Counter (response speed): 10MHz
