CHINO TP-L0260EN Small Thermal Image Sensor (-20 - 300oC, 0.1oC)

Manufaturer:	CHINO CORPORATION
Model:	TP-L0260EN

Product code

111-60094

Price 2,675.95 USD

Add to cart Buy now

*The above price is Standard Price, Kindly click on Request a quote to unlock Competitive Pricing and Delivery Dates - Check Availability. Our expert consulting team is always ready to assist you within one business day.

*Order Process: 1. Request a quote ⇒ 2. Quote via Email ⇒ 3. Proforma Invoice ⇒ 4. Payment ⇒ 5. Delivery and Invoice.

*We deliver to your doorstep under DAP terms. Customs clearance is for your account.

*You can't find the product you need, please send us the picture/specifications/model/product code and quantity you need to email: [email protected]. We will find it for you.

*Review us here: Review Now

Description

A reasonable price is achieved by adopting an FPA element with about 2000 pixels.
Compact and lightweight design.
In addition to thermal image monitoring using a PC, the sensor itself is equipped with an alarm contact output.
At the time of alarm output, one image is retained in the sensor body.
Abnormal heat generation monitoring of equipment.
Abnormal heat generation monitoring in production lines.
Monitoring heat and ignition of stored items.
Product temperature inspection in the inspection process (temperature distribution, hot spot/cool spot management).
Measurement temperature range (°C): -20 to 300
Temperature minimum display (°C): 0.1
Measurement viewing angle (°): 60 x 60
Spatial resolution (mrad): 21.8
Operating temperature range (°C): -10 to 50
Power supply: 12 to 24 VDC
Width x Depth x Height: 62 x 59 x 72mm
Degree of protection: IP65 (when using dedicated cable and fixing screws)
Number of pixels: 48 x 47
Frame time: 3Hz
Temperature resolution (°C): 0.5
Set contents/accessories:
Compact thermal image sensor body
1 lens cap
1 connector cap
1 fixing screw
1 pan head
Note:
Overseas sales prohibited. Available only in Japan.
Country of Origin: Japan
Code number: 461-9706
