Asco G435AK1N0050A00 Pneumatic Roundline Cylinder (16mm, 50mm Stroke)

Manufaturer:	Asco
Model:	G435AK1N0050A00

Product code

111-60049

Price 83.74 USD

Product discontinued

Add to cart Buy now

*This is standard price, please click "Request a quote" to see the actual price.

*You can't find the product you need, please send us the picture/specifications/model/product code and quantity you need to email: info@qtetech.com.vn. We will find it for you.

Description

ISO6432, CETOPRP52P and NF.E49030
ISO6432O12→25mm micro cylinder
Non-magnetic stainless steel body with stainless steel rod for excellent corrosion resistance. Double-acting types with and without cushions are available. Suitable for use with air/inert gas for lubricated/unlubricated magnetic position transducers filtered to 50μm.
Single-acting/double-acting types are available.
Quantity: 1 piece
Manufacturer Series: 435
Action: Single
Rod: Single
Bore: 16mm
Stroke: 50mm
Maximum working pressure: 10 bar
Cushion type: no cushion
Port connection: M5
Dimensions: 157 x 19 x 18mm
Height: 18mm
Operating temperature Max: +70°C
Operating Temperature Min: -10°C
RoHS Compliance Status: N/A
Code number: 815-7606
