Asco 19090017 Solenoid Valve 3 port

Asco 19090017 Solenoid Valve 3 port

Manufaturer: Asco
Model: 19090017
Product code
111-60043
Price 63.55 USD
Add to cart Buy now

✔ Note: Displayed prices are standard prices.

⚡ Please click Request a quote to unlock Competitive pricing and delivery dates within 24 hours.

✅ Guaranteed 100% Genuine (CO/CQ) – Free quote.

✈️ We deliver to your doorstep under DAP terms. Customs clearance is for your account.

✉️ Can't find the product you need? Please send the picture/specifications/model/product code to [email protected]. We will find it for you.

⭐ Review us here: Review Now ★ Trustpilot

Description

  • Control solenoid valves, 189 and 190 series
  • Range of 3/2 NF solenoid valves used to control ISO distributors
  • Possible to use solenoid valves independently using simple or juxtaposable manifolds
  • Choice of 3 coil voltages (ordered separately)
  • M5 threaded exhaust aperture
  • Compatible bases: CNOMO 06.05.80 and AFNOR NFE 49066.
  •
  • Quantity: 1 piece
  • Number of ports: 3
  • Operation: Pilot
  • Default valve position: NC
  • Applicable applications: filtered air, neutral gas
  • Type: 3/2
  • Orifice diameter: 1.6mm
  • Body Material: Aluminum
  • Maximum working pressure: 10 bar
  • Operating temperature range: -10 to +60 °C
  • Operating Temperature Min: -10°C
  • Operating temperature Max: +60°C
  • Maximum open time: 5ms
  • RoHS Compliance Status: Yes
  • Code number: 278-4429
