AS ONE 1-2186-12 AVO-250V Vacuum Dryer (V Series)

Manufaturer:	AS ONE
Model:	AVO-250V

Product code

111-33355

Price 2,581.51 USD

Add to cart Buy now

*This is standard price, please click "Request a quote" to see the actual price.

*You can't find the product you need, please send us the picture/specifications/model/product code and quantity you need to email: info@qtetech.com.vn. We will find it for you.

Description

Inner capacity (L): 15
Additional function: Timer function (ON/OFF/ON/OFF timer and SV start)
Sensor: K class thermocouple x 2 pieces (1 each for temperature control and overheating prevention)
Safety device: Over-rise prevention function (digital setting type), self-diagnosis function (Heater disconnection detection and sensor error detection), overcurrent breaker
material
*Exterior: Steel baked paint
*Interior: SUS304
*shelf board: Aluminium
*Valves, Piping, Fittings: brass (C -3771, C -3604)
*Vacuum gauge: brass (C 2680 TW, C 3604 BD)
*Door packing: silicone rubber
*Observation window: tempered glass (Thickness 12mm), protective plate made of polycarbonate
Outer dimensions (mm): 393 x 426 x 559
Inner dimensions (mm): 250 x 250 x 250
Heater capacity: 800W
Power supply: AC100V 50/60Hz 8A
Power cord length: 2.5 m
Weight: about 33kg
Accessories: shelf board x 2 pieces
Heating system: Can body heating system
Temperature settings range: 40 to: 220 °C
Vacuum range: 0.1 to 101kPa
Control method: PID control and SSR output
Valve diameter: outer diameter φ13 mm
