AKER CA4-10.000-18-3050-X AKER 10MHz Crystal (+/-30ppm, HC-49-US, SMD 4-Pin, 13 x 4.7 x 5.2mm)

AKER CA4-10.000-18-3050-X AKER 10MHz Crystal (+/-30ppm, HC-49-US, SMD 4-Pin, 13 x 4.7 x 5.2mm)

Manufaturer: AKER
Model: CA4-10.000-18-3050-X
Product code
111-58133
Price 223.01 USD
Add to cart Buy now

*The above price is Standard Price, Kindly click on Request a quote yes to unlock Competitive Pricing and Delivery Dates - Check Availability. Our expert consulting team is always ready to assist you within one business day.

*Order Process: 1. Request a quote ⇒ 2. Quote via Email ⇒ 3. Proforma Invoice ⇒ 4. Payment ⇒ 5. Delivery and Invoice.

*We deliver to your doorstep under DAP terms. Customs clearance is for your account.

Payment-Delivery

*You can't find the product you need, please send us the picture/specifications/model/product code and quantity you need to email: [email protected]. We will find it for you.

*Review us here: Review Now

Description

  • Quantity:1bag(250pieces)
  • Standard Frequency:10MHz
  • Mounting Type:Surface Mount
  • Load Capacitance:18pF
  • Package Type:HC-49-US SMD
  • Pin Count:4
  • Length:13mm
  • Width:4.7mm
  • Height:5.2mm
  • Dimensions:13 x 4.7 x 5.2mm
  • Frequency Tolerance:±30ppm
  • Frequency Stability:±50ppm
  • Series Resistance:50Ω
  • Minimum Operating Temperature:-40 °C
  • Maximum Operating Temperature:+85 °C
  • CODE No.:173-4368
